Product Overview
The GE IC695ACC413 is a replacement capacitor pack module designed for the GE Fanuc PACSystems RX3i platform, serving as a critical component within the IC695ACC403 Energy Pack . Engineered to preserve user memory and ensure seamless system recovery during power interruptions, this module directly replaces worn-out capacitor packs in energy storage units, maintaining backup power functionality for the IC695CPE330 and IC695CPE400 control processing units (CPUs) . With a 5-year capacitor lifespan under typical conditions (0–50°C), the IC695ACC413 ensures reliable operation in industrial environments where continuous uptime is essential.
Key features include hot-swap capability, allowing maintenance without system downtime, and self-diagnostic LED indicators (IN, STAT, OUT) for real-time monitoring of input power, charging status, and output voltage . Compliance with international safety standards (UL 508, CE Mark) further enhances its suitability for demanding applications in oil & gas, power generation, and water treatment facilities. The IC695ACC413 plays a vital role in ensuring uninterrupted control logic and data retention, making it an indispensable asset for mission-critical automation systems.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695ACC413 |
| Manufacturer | GE Fanuc |
| Product Type | Replacement Capacitor Pack Module for Energy Packs |
| Compatibility | Works with IC695ACC403 Energy Pack, IC695CPE330, and IC695CPE400 controllers |
| Input Voltage | 18–30 VDC (via energy pack backplane) |
| Output Voltage | 24 VDC (nominal, regulated by energy pack) |
| Capacitor Lifespan | 5 years @ 0–50°C; 4.5 years @ 60°C |
| Operating Temperature | -25°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Certifications | UL 508, CE Mark (EMC, LVD) |
| Connection Type | Direct integration with energy pack’s capacitor housing |
Key Features and Advantages
Extended Operational Lifespan: The IC695ACC413 restores the 5-year operational lifespan of energy packs under standard conditions, reducing replacement frequency compared to full energy pack replacement . This is particularly valuable in remote or hard-to-access installations, such as offshore rigs and mining sites, where downtime costs are high.
Hot-Swap Capability: Users can replace the capacitor pack while the system remains powered on, minimizing downtime during maintenance. This feature is critical for continuous-process industries like food and beverage production, where even brief interruptions can cause product loss .
Self-Diagnostic System: Real-time LED indicators on the energy pack provide clear status updates:
- IN: Green (input within range), red (input out of range)
- STAT: Blinking green (charging), solid green (fully charged), amber (nearing end-of-life), red (fault)
- OUT: Green (output stable), red (output fault)
This proactive monitoring enables predictive maintenance and prevents unexpected system failures .
Environmental Resilience: Withstands extreme temperatures (-25°C to 60°C) and harsh conditions in mining, arctic oil fields, and outdoor manufacturing facilities. The capacitor pack’s rugged design resists dust, moisture, and vibrations, ensuring reliable performance in challenging environments .
Applications
The GE IC695ACC413 excels in industrial scenarios requiring reliable backup power solutions:
- Oil & Gas: Safeguarding DCS systems in offshore platforms and refineries during transient power fluctuations. The module ensures control logic and diagnostic data remain intact, preventing costly production interruptions.
- Power Generation: Preserving turbine control parameters and diagnostic data in power plants during grid instability. This ensures seamless recovery and minimizes downtime in energy-critical operations.
- Water Treatment: Ensuring uninterrupted operation of pump control logic and SCADA systems during electrical grid outages. The IC695ACC413 maintains process continuity, preventing water supply disruptions.
- Transportation: Enabling real-time diagnostics in rail and automotive testing facilities by protecting data acquisition systems from road vibrations and weather exposure .
Related Products
IS200JPDCG1A Power Distribution Module
IS200STTCH2A GE Mark VI printed circuit board
General Electric IS420ESWBH2A, Industrial ESWB
IS230PCAAH1A REV C in Stock Buy
Installation and Maintenance
Installation Preparation:
- Power down the energy pack and disconnect it from the CPU.
- Remove the old IC695ACC413 capacitor pack by unscrewing the housing.
- Install the new IC695ACC413 and secure it with captive screws.
- Reconnect the energy pack to the CPU and power up the system. The STAT LED will indicate charging progress .
Maintenance Recommendations:
- Conduct quarterly inspections to check LED status and voltage outputs. Replace the IC695ACC413 if the STAT LED blinks amber (nearing end-of-life) or red (internal fault).
- Clean dust from energy pack vents using compressed air to maintain optimal thermal performance.
- Store spare IC695ACC413 modules in a static-free environment at temperatures between -20°C and 70°C .
Product Assurance
GE guarantees the IC695ACC413 against defects in materials and workmanship for 1 year from purchase. This warranty covers repair or replacement of faulty components, excluding damage caused by improper installation or misuse. Customers gain access to GE’s global technical support network, offering 24/7 assistance for troubleshooting and firmware updates. Regular maintenance services, including thermal cycling tests and capacitor health checks, are available through authorized partners to extend the module’s operational lifespan .
HS:8514909000
