Product Overview
The GE IC695ACC302 is a high-performance digital output module within GE’s PACSystems RX3i platform, designed for robust industrial automation applications. As part of the VersaMax series, this module delivers reliable control signal transmission for critical processes, supporting up to 35 output points with 24V DC sourcing capabilities. Engineered for harsh environments, the GE IC695ACC302 operates seamlessly across temperatures from -40°C to +70°C, ensuring stability in extreme conditions such as manufacturing floors or outdoor installations. Its integration with GE’s RX3i backplane enables high-speed PCI-based communication, reducing I/O update times and enhancing system responsiveness. The module’s compact design minimizes cabinet space while offering hot-swappable functionality for maintenance without downtime. For industries prioritizing precision and fault tolerance, the GE IC695ACC302 provides essential redundancy support, making it indispensable in safety-critical systems like energy production and chemical processing.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695ACC302 |
| Manufacturer | GE (General Electric) |
| Product Type | Digital Output Module |
| Output Type | 24V DC Sourcing |
| Number of Channels | 35 points |
| Current Consumption | 803 mA |
| Heat Dissipation | 8.8 BTU/hour |
| Operating Voltage | 24V DC ±10% |
| Operating Temperature | -40°C to +70°C |
| Communication Protocol | PCI-based backplane (RX3i) |
| Isolation | 1500V AC channel-to-backplane |
| Certifications | CE, UL, RoHS |
| Dimensions | 200 × 120 × 75 mm (estimated) |
| Weight | 0.3 kg |
Key Features and Advantages
High-Density Output Configuration: With 35 isolated output channels, the GE IC695ACC302 optimizes control cabinet space, reducing hardware footprint by 40% compared to legacy modules. Each channel supports 24V DC sourcing at 0.5A, enabling direct control of actuators, solenoid valves, and indicator lights without external relays.
Robust Environmental Resilience: Engineered for IP20-rated enclosures, this module withstands industrial contaminants, vibration, and thermal cycling. Extended operational range (-40°C to +70°C) ensures reliability in foundries, substations, and offshore platforms.
Seamless System Integration: Native compatibility with PACSystems RX3i CPUs (e.g., IC695CPE310) and GE’s Proficy Machine Edition software simplifies configuration. Real-time diagnostics via LED per channel accelerate fault isolation, cutting mean-time-to-repair (MTTR) by 30%.
Hot-Swap Maintainability: Modules can be replaced during operation, eliminating process interruptions. Combined with dual-slot redundancy support, this feature delivers >99.99% availability for continuous processes like water treatment SCADA systems.
Application Areas
The GE IC695ACC302 excels in discrete manufacturing for conveyor sequencing and robotic cell control, where its millisecond response time synchronizes high-speed assembly lines. In energy infrastructure, it drives grid protection relay logic and turbine auxiliaries, leveraging surge immunity (4kV ANSI C37.90) for substation environments. Water/wastewater plants deploy it for pump station control and chemical dosing valves, utilizing its corrosion-resistant terminals for humid environments. Additionally, building management systems integrate the module for HVAC damper control and emergency lighting, capitalizing on low standby power (<1W) for sustainable operations.
Related Products
- IS200JPDCG1A Power Distribution Module
IS200STTCH2A GE Mark VI printed circuit board
Installation and Maintenance
Installation Prep: Verify backplane voltage (5V ±5%) before mounting IC695ACC302. Use shielded twisted-pair cables for outputs exceeding 3m, grounding shields at the module end. Ensure chassis ground resistance <1Ω.
Maintenance: Monitor heat dissipation via integrated thermal sensors; clean air filters quarterly in dusty environments. Replace terminals after 10,000 insertion cycles to maintain contact integrity.
Product Assurance
Every GE IC695ACC302 module includes a 36-month warranty against manufacturing defects. GE’s global technical support provides 24/7 firmware updates and failure analysis, with advance replacement for critical failures within 48 hours.
